1d 2D Fixed Mount Barcode Scanner Reader USB RS232 Interface for Pdf417& Kiosk

Overview

Basic Info.

Model NO.	MS-7710N
Transport Package	One PC/Per Carton
Specification	Dimension: 64.8(W)*60.5(D)*21.2(H)mm
Trademark	Masung
Origin	China
HS Code	84716050
Production Capacity	5000PCS/Per Month

Product Description

Product DescriptionMS-7710NBarcode Scanner Module EngineFull code system of 1D & 2D QR codeWide Voltage Design High Integration of mini size Features:*Leading Industrial Decoding Technology*Support for Barcode on Paper&Screen*Multiple interface: USB, USB COM, TTL 232, RS232, TTL3.3V, TTL5V etc.*Ultra-thin design with thickness of 21mm*Support reading of 1D & 2D code Product Parameters

Model			7710N	7710NS
Scanning Performance Performance	Image sensor		640×480 CMOS
	Lighting		white light LED (6500k)
	Coding	2D	PDF417, Micro PDF417, Data Matrix, QRCode , Micro QRCode , Maxi Code, Aztec Code, Han XIN CODE etc
		1D	Interleaved 2of 5, ISBN, Code 93, Code 11, UCC/EAN-128 GS1Databar, Matrix 2of 5, Industrial 2of 5, Code 128, EAN-13, EAN-8, Code 39, UPC-A, UPC-E, Codabar, Standard 2of 5, MSI-Plessey, GS1composite code, etc
	Resolution		≥4 mil	≥3mil
	Depth of Field	Alipay Payment code	40-300 mm (Phone screen size 5.5 inches based on lens front face)	40-360 mm (Phone screen size 5.5 inches based on lens front face)
		WeChat Payment Code	35-270 mm (Phone screen size 5.5 inches based on lens front face)	35-330 mm (Phone screen size 5.5 inches based on lens front face)
	Symbol Contrast		≥20%
	Bar code sensitivity		Tilt ±60°, deflection ±55°, rotation 360°
	View angle		Level 60°, vertical 48°
	Motion tolerance		≥20cm/s	≥200cm/s
Mechanical/ Electrical Parameters	Communication interface		TTL /RS -232,USB ,USB COM ,TTL3.3V ,TTL5V
	Dimension (mm)		64.8(W)×60.5(D)×21.2(H)mm
	Weight		30 g
	Working voltage		3.3-6 V
	Rated Current		(typical value) less than 190 mA (5 V input)
Environmental Parameters	Working temperature		-20ºC~+60ºC
	Storage temperature		-40ºC~+70ºC
	Working humidity		5%~95%(no condensation)
	Environment Light		~100,000 LUX
Impact Resistance	Maximum temperature		60°C (140°F )
	Minimum temperature		-20°C (-4°F)
	Times of cycles		30 minutes high temperature; 30 minutes low temperature
	Period		24
Mechanical Impact Resistance	Vibration		2000G, 0.7ms, half sinus, 3axes
	Drop Resistan		Can withstand 1.2 m drop to cement ground
Certificate	International certification
