Fixed Mount Scanner 1d, 2D Fixed Mount Barcode Scanner Reader USB RS232 Interface for Pdf417 Passport & Kiosk

Overview

Basic Info.

Model NO.	MS-4200H
Interface	USB, USB COM, RS232
Rated Current	Below 190mA
Image Sensor	1280 X 800 Pixels
Input Voltage	5VDC
Reading Accuracy	2D5mil, 1d3.3mil
Product Name	Green Pass Scanner and Qr Code Scanner
Barcode Sensitivity	Tilt50deg, Deflection:55deg, Rotation 360
Code Reading	1d+2D+Qr Code +ID Card +Passport
Transport Package	180PCS/Per Carton
Specification	49mm x 37.5mm x 25mm
Trademark	Masung
Origin	Guangdong
HS Code	84716050
Production Capacity	50000 Set/Sets Per Month

Product Description

Product DescriptionFeatures:
1.Leading decoding technology
Using self-developed core technology,
extremely fast response,Support rapid
development and customization requirements
2.Industrial-grade circuit protection
Using pure industrial-grade
circuit protection design, more stable
3.High-end laser cross cursor positioning
Using industrial-grade laser cross cursor
positioning instructions, positioning instructions
Show more clearly
4.OCR reading function
In addition to one-dimensional
and two-dimensional reading capabilities, it also has sensitive ID card and passport OCR reading capabilities
5.Multi-interface mode communication
Through the optional adapter board, USB, USB COM, RS232 communication modes can be realized

Application:
PDA, medical self-service, immigration equipment, airport boarding, access control machine, desktop self-service,self-service inquiry, queuing number, financial self-service equipment, etc., are more suitable for scenarios that require high-density paper barcodes and OCR codes.

Product Parameters

	Model no		MS-4200	MS-4200H
Scanning performance	Image Sensor		640 X 480 Pixels	1280 X 800 Pixels
	Acquisition speed		1/120S	1/60S
	Illumination/Locating Light		white LED(6500K)/Red, cross envelope
	Code system	2D	Comply with international and domestic general QR code standards:QR Code, Data Matrix, PDF417,Han Xin Code,Dotcode etc
		1D	Comply with international and domestic general QR code standards:UPC-A, UPC-E, EAN-8, EAN-13, ISBN, Code 128, GS1 128, ISBT 128, Code 39, Code93,Code 11, Interleaved 2 of 5, Industrial 2 of 5,Matrix 25, Standard 25, Codabar, MSI/MSI PLESSEY, GS1 DataBar etc
		OCR	Comply with OCR-A, OCR-B font standards (*customized version)
	Reading accuracy		2d≥5mil,1d≥4mil	2d≥5mil,1d≥3.3mil
	Typical reading depth of field	Code 39 4mil	40~120mm	60~160mm
		Code 128 5mil	30~170mm	40~230mm
		Code 39 20mil	60~320mm	70~420mm
		PDF417 5mil	30~120mm	40~220mm
		Data Matrix 10mil	20-100mm	35-210mm
		QR Code 20mil	30~210mm	35~340mm
	Contrast		≥20%
	Barcode sensitivity		Tilt±50°,deflection±55°,Rotation 360°
	Field of view angle		Diagonal52°,Horizental 42°,Vertical32°
Mechanical /electrical parameters	Interface		USB,USB COM,RS232
	Dimension(mm)		49mm x 37.5mm x 25mm
	Weight		35g
	Input voltage		5V DC
	Rated current		Below 190mA
Environmental parameters	Operating temperature		-30ºC~+70ºC
	Storage temperature		-40ºC~+80ºC
	Working humidity		5%~95%(No condensation)
	Ambient light		0~100,000LUX
